Model a Modern Spiral Staircase in 3ds Max

on Dec 19th 2009 with 63 comments
Tutorial Details

Final Product What You'll Be Creating

In this tutorial Ben Tate will demonstrate his approach to modeling a modern style spiral staircase in 3d Studio Max. The main focus will be spline modeling, although Ben will reiterate some of the more common poly modeling techniques too.

We will begin the tutorial by creating one of the steps and a simple railing post, and then look at cloning and positioning these objects into the necessary spiral pattern. Once that has been achieved, we will discuss how we can create and align the stair railing. Then, with the staircase complete, we will move on to create a hole in the upper floor for our staircase to pass through, and finish off the top landing by adding a circular railing. Finally, we will make any required adjustments to our splines, and finish the project off by organizing our scene.

Additional Files/ Plugins:

  • Download the Reference Materials for this tutorial

      • Video 1

      Download

      Note: click the ‘Monitor’ icon to view tutorial in full-screen HD.

      Video 2

      Download

      Note: click the ‘Monitor’ icon to view tutorial in full-screen HD.

      Don’t miss more CG tutorials and guides, published daily – subscribe to Cgtuts+ by RSS.


Enjoyed this Post?

Subscribe to our RSS Feed, Follow us on Twitter or simply recommend us to friends and colleagues!

By

Rollover to read this author's bio or click through to see a full list of posts by this author.

Ben is one half (literally) of the editor duo here at Cgtuts+. Ben has over eight years of experience in the computer graphics field and although he's primarily a hard surface modeler, he's also experienced in the fields of uvmapping, texturing, lighting and rendering. He has authored many tutorials and training materials focused on 3d Studio Max and hard surface modeling. You can check out Ben's website at bentateonline.com to see more of his work.
